Milesight Tilt Sensor is Angling for Accuracy, Flexibility and Safety.
- High Accuracy and Reliability
- Flexible Settings for Versatile Applications
- Artful Design and Robust Enclosure
Milesight Tilt Sensor is Angling for Accuracy, Flexibility and Safety.
Built-in MEMS accelerometer sensor to measure the 3-axis angles of any objects
Flexible threshold condition settings, suitable for different kinds of applications
Easy to install, suitable for various types of objects as trees, poles, grounds, etc. IP67 waterproof enclosure for outdoor applications
Anti-theft design on back cover to secure firm and sturdy installation
Ultra-wide-distance wireless transmission up to line of sight of 15 km
Equipped with NFC for one touch configuration
Function well with standard LoRaWAN® gateways and network servers
Compliant with Milesight IoT Cloud
| Category | Specification |
|---|---|
| Wireless Transmission | |
| Technology | LoRaWAN® |
| Antenna | Internal Antenna |
| Frequency | CN470 / IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923-1&2&3&4 |
| Tx Power | 16 dBm (868 MHz) / 22 dBm (915 MHz) / 19 dBm (470 MHz) |
| Sensitivity | -137 dBm @ 300 bps |
| Mode | OTAA / ABP Class A |
| Measurement | |
| Axis | X, Y, Z |
| Range | -90° to +90° |
| Accuracy | ±1° |
| Resolution | 0.01° |
| Others | |
| LED | 1 × Internal LED Indicator |
| Button | 1 × Internal Power / Reset Button |
| Software | |
| Power On & Off | NFC Configuration via Mobile App, Power Button (Internal) |
| Configuration | NFC Configuration via Mobile App |
| Advanced Feature | Threshold Alarm |
| Physical Characteristics | |
| Power Supply | 2 × 2700 mAh ER14505 Li-SOCl₂ Batteries |
| Battery Life | Around 4 Years (SF7, EU868 & US915) Around 3 Years (SF10, EU868 & US915) |
| Operating Temperature | -30°C to +60°C |
| Relative Humidity | ≤95% (non-condensing) |
| Ingress Protection | IP67 |
| Dimension | 85 × 58 × 18 mm (3.34 × 2.28 × 0.70 in) |
| Housing & Color | PC + ABS, White |
| Installation | Wall Screw Mounting / Pole Mounting |
| Approvals | |
| Regulatory | CE, FCC, Telec |
| Environmental | RoHS |
